• Emergency Stop (E-stop) and Main power disconnect.
• NEMA 12 Free Standing Motor Control Enclosure.
• 480V/3 Phase/60 Hz.
• Includes burner PID controls.
• Flame safeguard controls.
• Digital Temperature read-outs for the inlet and outlet air streams.
• Motor Starters for:
o Qty 2 – 5 HP w/ VFDs
o Qty 2 – 15 HP
o Qty 3 – 3 HP w/VFDs
o Qty 1 – 0.5 HP w/ VFD
o Qty 2 – 2 HP
o Qty 2– 7.5 HP motors
• Includes 120VAC and 24VDC power supplies and power distribution.
Lightly used rotary screener (also called a centrifugal sifteer) with less than 40 hours of use.
Very lightly used OvenPak 435 burner from the hemp industry.
Very lightly used OvenPak 435 burner from the hemp industry.
Automated solenoid to engage suppression system for both dryer and baghouse
Thermocouple rated for 400°F inserted in baghouse
Independent enclosure with HOA control
Spray ball inserts on top of dryer
Spray ball inserts on Baghouse
These batch dryers gently heat biomass in a highly ventilated & controlled space over the course of 8 hours. They are coming used from Columbia Hemp Trading Co. for $80k including training, SOP, and a technician to assist on setup.
Lightly used centrifugal sifter with less than 40 hours of use! Motor: 7.5HP, 230/460, 3PH, 60HZ, 1800RPM TEFC (Totally Enclosed, Fan-Cooled), Externally Mounted
Screen Size: 1/8ӯ offset for separation of stalks/stems from desirable biomass
Product Contact Parts: 304 Stainless Steel, Glass Bead Finish
Non-Product Contact Parts: Carbon Steel, White Paint
Special High Pitch Paddle
3″Ø Dust Port
ASME 8″Ø 150lb Flange Inlet
ASME 16″Ø 150lb Flange Screened Product Discharge
8″Ø Unscreened Product Discharge
Air purge seal bearing
• Model K72/84-1 FBD-SS – 72” diameter High Efficiency VIBROBED Fluid Bed Dryer, constructed of 304.
• Stainless steel product contact parts.
• Adjustable Weir (with plough) will be provided to vary bed depth and control retention time.
• 304 Stainless Steel Material Contact Parts with glass bead finish.
• PS-72-7/32BA Perforated Plate Screen Installed.
• 304 Stainless Steel Dust Cover.
• 1 ea. 8”Ø Product inlet port.
• 1 ea. 20”Ø Product discharge port.
• 1 ea. 20”Ø Air exhaust port.
• 2 ea. 6”Ø Inspection ports.
• Two (2) Externally Mounted 1.1 HP, 230/460 Volts, 3 Phase, 60 Hz TENV Vibrator Motors with adjustable amplitude of vibration Installed.
• 6” OAL Carbon Steel Mount Frame.
• Miscellaneous FBD Ducting:
o FBD Inlet Fan to Burner Combustion Chamber Transition
o Burner Air Bleed In Baffle
o Ducting for Burner Air Bleed In
o Elbow for burner air to inlet of FBD
Used Quad-Shaft industrial shredder for sale from the hemp industry with less than 40 hrs. of operation under its belt! Teeth and motors in are in excellent shape and it is ready to ship from Colorado. Call or fill out the form below for more information.
8,000 CFM Schenck Dust Collection System complete with a fire suppression system, control panel, ducting, and stainless steel contact points. Previously from the hemp industry, this baghouse is like-new with ~40 hrs. on it.
Integration with your system is available.
